Introduction
- Interactive Flat Panel, also referred to as touch screen displays or interactive touch screens, are often large, wall or cart mounted displays. These systems allow users to manipulate data in a hands-on environment and engage with content like never before.
- Interactive Flat Panel K series is a piece of equipment that lets users interact with a computer by touching the screen directly. Incorporating features into the monitor like sensors that detect touch actions makes it possible to issue instructions to a computer by having it sense the position of a finger or stylus.
Features
- Rounded corner design, 1cm ultra-narrow frame, no sharp corners;
- Mohs 7 tempered explosion-proof glass; as solid as a rock;
- 178° full viewing angle HD high-definition large screen, delicate picture quality, perfect presentation;
- 20-poins multi-touch, writing as you like;
- Intel standard 80pin OPS interface, pluggable design, easy to maintain and upgrade;
- Front USB expansion port, convenient for data exchange;
- One-key switch on the front of the monitor and OPS computer, easy to operate;
- Intelligently identify the signal source, and automatically jump into the port channel when the external signal is connected;
- Smart and easy to use, efficient teaching.
Technical parameters
| Display Parameters | Size | 65″ |
| Panel Type | LG | |
| LED Type | LED backlight | |
| Resolution | 3840*2160 pixels | |
| Brightness (typ)/(min) | 250 cd/㎡(typ.) | |
| Contrast Ratio (typ)/(min) | 1300:1 (typ.) | |
| Response Time(typ)/(min) | 9ms (typ.) | |
| Point Distance | 0.315×0.315 mm | |
| Frame rate | 60 Hz | |
| Visual angle | 178 (H) / 178 (V) | |
| Life Time(typ)/(min) | 50,000 hrs (min.) | |
| Viewing area | 1428.48(H)*803.52(V) | |
| Colorfulness | 1.07 Billion | |
| System Properties | Solution | MSTAR |
| CPU | MSD6190HB | |
| Internal cache capacity (RAM) | 64Mbit | |
| Power | Voltage | 100 V ~ 240 V, 50-60 Hz |
| Maximum Power | ≤130W | |
| Standby Power | ≤0.5W | |
| Internal Speaker | 10W × 2 | |
| Touch | IR 20Points | Support |
| Structure | NW | 39.5Kg |
| GW | 47Kg±1.5 Kg | |
| Dimensions (W x D x H) | 1485.0×887.6×91.7mm | |
| Packaging(W x D x H) | 1595*225*988mm | |
| Shell Material | Aluminum Profile Metal | |
| Shell Color | Silver or Black | |
| VESA Hole Position | 4-M8 Screw Hole | |
| Built-in PC (optional) | CPU | I3/I5/I7 |
| RAM | 4G DDR3 | |
| Hard Disk | 500G/SSD128G | |
| OS | WIN10 | |
| Whiteboard Software | Yes |
